2200uf/200v Electrolytic Capacitor
| Parameter | Details |
|---|---|
| Capacitance | 2200 µF |
| Rated Voltage | 200V DC |
| Capacitance Tolerance | ±20% (standard for electrolytics) |
| Ripple Current | ~2.5 A to 6 A RMS @ 100 Hz / 120 Hz (depends on series & manufacturer) |
| Equivalent Series Resistance (ESR) | ~30–80 mΩ @ 100 Hz (varies with model) |
| Leakage Current | ~0.01CV or 3 mA max after 1 minute (C in µF, V in volts) |
| Operating Temperature | -40°C to +85°C / +105°C (depends on type) |
| Endurance / Lifetime | 2,000 to 10,000 hours @ full load and 85–105°C (manufacturer-specific) |
| Mounting Type | Through-hole (Snap-in) or Screw terminal |
| Can Size (typical) | e.g., 35×50 mm, 35×60 mm (diameter × height – varies by brand) |
| Polarity | Polarized (must observe + and - markings) |
| Safety Features | Pressure relief vent, epoxy sealed base (optional flame retardant) |
| RoHS / REACH Compliant | Yes (for most modern components) |
