471pf/2kv Disc Capacitor
| Parameter | Details |
|---|---|
| Capacitance | 4700 pF (4.7 nF) |
| Capacitance Code | 471 (47 × 10¹) |
| Rated Voltage | 2000V (2kV) DC |
| Tolerance | ±10% (Code: K) or ±20% (Code: M) – depends on part |
| Dielectric Type | Ceramic, typically Class II (e.g., X7R, Y5V) |
| Temperature Coefficient | X7R: ±15% over -55°C to +125°C (stable) Y5V: +22%/-82% over -30°C to +85°C |
| Operating Temperature | Typically -40°C to +125°C |
| Insulation Resistance | >10,000 MΩ at 500V DC (typical) |
| Dissipation Factor | ≤2.5% at 1 kHz (for Class II ceramics) |
| Mounting Type | Through-hole (radial leads) |
| Lead Pitch / Spacing | Commonly 5 mm or 7.5 mm (varies with manufacturer and case size) |
| Body Material | Flame-retardant epoxy-coated ceramic disc |
| Flammability Rating | UL94V-0 (typically for coated types) |
| RoHS Compliance | Yes |
