47uf/50v Electrolytic Capacitor
| Parameter | Details |
|---|
| Capacitance | 47 µF (microfarads) |
| Rated Voltage | 50V DC (maximum continuous DC voltage) |
| Capacitance Tolerance | ±20% (standard tolerance for most electrolytic capacitors) |
| ESR (Equivalent Series Resistance) | Typically ≤ 0.1 Ω to 0.5 Ω at 100 kHz (depends on manufacturer) |
| Leakage Current | Typically ≤ 0.01CV or 0.03 mA max (C in µF, V in volts) |
| Operating Temperature Range | -40°C to +85°C (or higher depending on the specific capacitor) |
| Package Type | Axial or Radial (depending on type) |
| Body Size | Commonly 8x12 mm, 10x16 mm, or other sizes (depending on brand) |
| Lifespan / Endurance | Typically 2,000 to 5,000 hours at full rated voltage and 105°C |
| Polarity | Polarized (must observe + and - markings) |
| Ripple Current | Typically 100 mA to 200 mA (depends on capacitor size and voltage) |
| RoHS Compliant | Yes |
